Reports Guide (Jasper Reports)

Add the company logo to a report

• Create a parameter named loginLegalEntityLogo with type java.lang.Object or java.io.InputStream

• Create an image, image expression should be $P{loginLegalEntityLogo}

• To add any attachment to a report:

NamaRep.getFile($F{attachmentId})
//OR
NamaRep.getAttachment($F{attachmentId})

System Parameters in Reports

loginLanguage: Arabic, or English
formEntityType: the entity type for the form (Can be used for translation)
loginLegalEntityId
loginLegalEntityCode
loginLegalEntityName1
loginLegalEntityName2
loginLegalEntityLogo
loginLegalEntityLogo2
loginLegalEntityLogo3
loginLegalEntityLogo4
loginLegalEntityLogo5
reportsFooterNote1
reportsFooterNote2
loginSectorId
loginSectorCode
loginSectorName1
loginSectorName2
loginBranchId
loginBranchCode
loginBranchName1
loginBranchName2
loginAnalysisSetId
loginAnalysisSetCode
loginAnalysisSetName1
loginAnalysisSetName2
loginDepartmentId
loginDepartmentCode
loginDepartmentName1
loginDepartmentName2
loginUserId
loginUserTreatAsAuthorIds
loginUserCode
loginUserName1
loginUserName2
loginEmployeeId
publicLegalEntityId
publicSectorId
publicBranchId
publicDepartmentId
publicAnalysisSetId
guiServerURL
externalServerURL
loginLanguage
originalLoginLanguage
formEntityType
analysisSetNotUsedInSecurity
sectorNotUsedInSecurity
departmentNotUsedInSecurity
branchNotUsedInSecurity
legalEntityNotUsedInSecurity
accessibleAnalysisSetIds
accessibleDepartmentIds
accessibleBranchIds
accessibleLegalEntityIds
accessibleSectorIds
concernedLines
candidateEmployeeId
candidateEmployeeCode
candidateEmployeeName1
candidateEmployeeName2
approvedRecordId
approvedRecordType
approvedRecordCode
approvalSecret
approvalStepSeq
reportCode
reportName1
reportName2
reportId
namaReportInstance
currentGUIURL
currentReplicationSited
currentReplicationSiteCode
currentReplicationSiteName1
currentReplicationSiteName2
allowedCapabilities
allowedEntities
allowedDocuments
allowedFiles
notAllowedEntities
notAllowedDocuments
notAllowedFiles
posShiftCode
runId

NamaRep.dayName($F{dateField})
NamaRep.enDayName($F{dateField})
NamaRep.arDayName($F{dateField})

NamaRep.translate(enumValue)

NamaRep.name(arabic,english)

NamaRep.priceCalculator().item($F{item}).uom($F{UOM}).qty($F{Quantity}).unitPriceOnly().price()

• The following is a list of all functions you can use to create a price calculation request
• The price() or unitPrice() function must be the last one in the expression

item($F{itemIdOrCode})
customer($F{customerIdOrCode})
supplier($F{supplierIdOrCode})
uom($F{uomIdOrCode})
invoiceClassification($F{classificationIdOrCode})
ic($F{classificationIdOrCode})
legalEntity($F{legalEntityIdOrCode})
le($F{legalEntityIdOrCode})
sector($F{sectorIdOrCode})
sc($F{sectorIdOrCode})
branch($F{branchIdOrCode})
br($F{branchIdOrCode})
department($F{departmentIdOrCode})
dep($F{departmentIdOrCode})
analysisSet($F{analysisSetIdOrCode})
anset($F{analysisSetIdOrCode})
priceClassifier1($F{priceClassifier1IdOrCode})
pc1($F{priceClassifier1IdOrCode})
priceClassifier2($F{priceClassifier2IdOrCode})
pc2($F{priceClassifier2IdOrCode})
priceClassifier3($F{priceClassifier3IdOrCode})
pc3($F{priceClassifier3IdOrCode})
priceClassifier4($F{priceClassifier4IdOrCode})
pc4($F{priceClassifier4IdOrCode})
priceClassifier5($F{priceClassifier5IdOrCode})
pc5($F{priceClassifier5IdOrCode})
revision($F{revision})
color($F{colorCode})
size($F{size})
qty($F{qty})
date($F{date})
unitPriceOnly()

• Assuming the variable you created is named price, here is a list of all expressions you can use to extract price components

$V{price}.custom.primitiveValue
$V{price}.discount1.afterValue.primitiveValue
$V{price}.discount1.maxNormalPercent.primitiveValue
$V{price}.discount1.percentage.primitiveValue
$V{price}.discount1.value.primitiveValue
$V{price}.discount2.afterValue.primitiveValue
$V{price}.discount2.maxNormalPercent.primitiveValue
$V{price}.discount2.percentage.primitiveValue
$V{price}.discount2.value.primitiveValue
$V{price}.discount3.afterValue.primitiveValue
$V{price}.discount3.maxNormalPercent.primitiveValue
$V{price}.discount3.percentage.primitiveValue
$V{price}.discount3.value.primitiveValue
$V{price}.discount4.afterValue.primitiveValue
$V{price}.discount4.maxNormalPercent.primitiveValue
$V{price}.discount4.percentage.primitiveValue
$V{price}.discount4.value.primitiveValue
$V{price}.discount5.afterValue.primitiveValue
$V{price}.discount5.maxNormalPercent.primitiveValue
$V{price}.discount5.percentage.primitiveValue
$V{price}.discount5.value.primitiveValue
$V{price}.discount6.afterValue.primitiveValue
$V{price}.discount6.maxNormalPercent.primitiveValue
$V{price}.discount6.percentage.primitiveValue
$V{price}.discount6.value.primitiveValue
$V{price}.discount7.afterValue.primitiveValue
$V{price}.discount7.maxNormalPercent.primitiveValue
$V{price}.discount7.percentage.primitiveValue
$V{price}.discount7.value.primitiveValue
$V{price}.discount8.afterValue.primitiveValue
$V{price}.discount8.maxNormalPercent.primitiveValue
$V{price}.discount8.percentage.primitiveValue
$V{price}.discount8.value.primitiveValue
$V{price}.headerDicount.afterValue.primitiveValue
$V{price}.headerDicount.maxNormalPercent.primitiveValue
$V{price}.headerDicount.percentage.primitiveValue
$V{price}.headerDicount.value.primitiveValue
$V{price}.netValue.primitiveValue
$V{price}.${price}.primitiveValue
$V{price}.tax1.afterValue.primitiveValue
$V{price}.tax1.maxNormalPercent.primitiveValue
$V{price}.tax1.percentage.primitiveValue
$V{price}.tax1.value.primitiveValue
$V{price}.tax2.afterValue.primitiveValue
$V{price}.tax2.maxNormalPercent.primitiveValue
$V{price}.tax2.percentage.primitiveValue
$V{price}.tax2.value.primitiveValue
$V{price}.tax3.afterValue.primitiveValue
$V{price}.tax3.maxNormalPercent.primitiveValue
$V{price}.tax3.percentage.primitiveValue
$V{price}.tax3.value.primitiveValue
$V{price}.tax4.afterValue.primitiveValue
$V{price}.tax4.maxNormalPercent.primitiveValue
$V{price}.tax4.percentage.primitiveValue
$V{price}.tax4.value.primitiveValue
$V{price}.totalCashShare.primitiveValue
$V{price}.totalPaymentMethodShare.primitiveValue
$V{price}.unitPrice.primitiveValue

Here's a clean and organized version in English, suitable for your VuePress documentation site:

Links to Entities, Attachments, and Reports

Entity Links

• Create a simple link to an entity:

  NamaRep.link(entityType, id)


• Create a link to an entity using menu code and view name:

  NamaRep.link()
    .entityType($F{entityType})
    .id($F{id})
    .viewName("theViewName")
    .menuCode("abcMenu")
    .toString();


Attachment Links

• Create a link to an attachment (file):

  NamaRep.attachmentLink(id)


Report Links

• Create a link to another report:

  NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "ReportCode")
    .p("p1 id").v(value expression)
    .p("p2 id").v(value expression)
    .toString()


• Copy all shared parameters from the current report:

  NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "code").copyParams()


Add Reference Parameters

Use any of the following expressions to pass references:

v($F{id}, $F{entity}, $F{code}, $F{name1}, $F{name2})
v($F{id}, $F{entity}, $F{code})
ref($F{entityType}, $F{id})
refCode($F{entityType}, $F{code})

Report Link Examples

NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "Statement")
  .copyParams()
  .p("fromAccount").v($F{accountId}, $F{accountEntityType}, $F{accountCode})
  .p("toAccount").v($F{accountId}, "Account", $F{accountCode})
  .toString()

NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "SalesProfitSummary")
  .copyParams($P{REPORT_PARAMETERS_MAP})
  .p("SalesInvoice").ref("SalesInvoice", $F{SSIid})
  .p("cust").refCode("Customer", "Customer501")
  .p("fromDate").v("23-04-2014")
  .p("showDetails").v("true")
  .toString()

NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "SubsidiaryAccountStatement")
  .p("subsidiaryType").v($F{CustomerEntityType})
  .p("fromSubsidiary").v($F{customerId}, $F{CustomerEntityType}, $F{customerCode})
  .p("toSubsidiary").v($F{customerId}, $F{CustomerEntityType}, $F{customerCode})
  .p("accuontType").v("mainAccount")
  .toString()

Public Report Links (No Authentication)

To share a report link externally (e.g. to a customer) without requiring login:

NamaRep.repLinkByCode($P{REPORT_PARAMETERS_MAP}, "ARG000046-report")
  .p("Code_Equals").ref($F{entityType}, $F{id})
  .toNoAuthResultLink()

NamaRep.shortenURL(serverurl, signature, url)

Creating Entities from Reports (Creators)

• Example: create a Receipt Voucher from an Invoice:

  NamaRep.newWithFields("ReceiptVoucher")
    .f("term").value("POTermCode")
    .f("book").value("POBook1")
    .f("remarks").v("Auto Created")
    .f("fromDoc#type").v("SalesInvoice")
    .f("fromDoc#code").v($F{code})
    .toString()


• You can also use:

NamaRep.creator("ReceiptVoucher")

Creating with Line-Level Details

1. Create a variable called creatorLink with initial value expression:

NamaRep.newWithFields("PurchaseOrder").field("term").value("P.Order.Term").root()

2. For line-level expression:

$V{creatorLink}.field("details.item.itemCode").value($F{code}).row($V{REPORT_COUNT})

3. To generate the full link:

$V{creatorLink}.toString()

Optional: Specify Menu Code or View Name

NamaRep.newWithFields("ReceiptVoucher")
  .viewName("NormalReceipts")
  .menuCode("NormalReceiptMenu")
  .f("term").value("POTermCode")
  .f("book").value("POBook1")
  .toString()

Find employee vacation balances

NamaRep.getVacation1RemainderBalance(empIdOrCode)
NamaRep.getVacation2RemainderBalance(empIdOrCode)
NamaRep.getVacation3RemainderBalance(empIdOrCode)
NamaRep.getVacationRemainderBalance(empCodeOrId,vacationTypeIdOrCode)
NamaRep.getVacationRemainderBalance(empCodeOrId,vacationTypeIdOrCode,atDate)

Approvals in Reports

• Create Links to approve, reject, return, and so on

NamaRep.approveAllLink($P{REPORT_PARAMETERS_MAP})
NamaRep.rejectAllLink($P{REPORT_PARAMETERS_MAP})
NamaRep.returnAllLink($P{REPORT_PARAMETERS_MAP})
NamaRep.returnAllToPreviousStepLink($P{REPORT_PARAMETERS_MAP})

• If you have approval per line (concerned lines, used mainly in supply chain documents)

NamaRep.approveLink($P{REPORT_PARAMETERS_MAP},$F{lineNumber})
NamaRep.approveLink($P{REPORT_PARAMETERS_MAP},$F{lineNumber},reasoncodeOrId) // same for all remaining links
NamaRep.rejectLink($P{REPORT_PARAMETERS_MAP},$F{lineNumber})
NamaRep.returnLink($P{REPORT_PARAMETERS_MAP},$F{lineNumber})
NamaRep.returnToPreviousStepLink($P{REPORT_PARAMETERS_MAP},$F{lineNumber})

• Another alternative would be to use the approveAllLink method

NamaRep.approveAllLink($P{REPORT_PARAMETERS_MAP},decision)

• To show approval dialog by clicking on a link, use the following code sample

NamaRep.approveFromJS(entityType, entityId, nextStepName, concernedLines, nextStepSeq, summary)

• Find if a line is concerned in approval

NamaRep.isConcernedLine($P{REPORT_PARAMETERS_MAP},$F{lineNumber})

Run SQL Statement inside a report

NamaRep.runSQLQuery(sql,paramName,paramValue,paramName,paramValue)

Transform HTML to text (HTML Parsing)

NamaRep.htmlToText(text)

Miscellaneous

Time To String Functions in Reports

• NamaRep.timeToString: converts milliseconds to hours:minutes, example 9120000 becomes 02:32
• NamaRep.timeToStringNullable: same as previous, but 0 is converted to null instead of 00:00
• NamaRep.decimalToString: converts hours to hours:minutes, example 9.5 becomes 09:30 and 9.25 becomes 9:15
• NamaRep.decimalToStringNullable: same as previous, but 0 is converted to null instead of 00:00

To convert date to Hijri

NamaRep.toHijri($F{date})
NamaRep.hijriDay($F{date})+"/"+NamaRep.hijriMonth($F{date})+"/"+NamaRep.hijriYear($F{date})
NamaRep.hijri_yyyyMMdd($F{date})

To execute query:

NamaRep.executeQuery("select cast(w.name1 collate Arabic_CI_AI_KS_WS as varchar(250)) from warehouse w where w.id = :wid"
        ,"wid",$F{wid})

To Get Configuration Field:

NamaRep.getValueFromModuleConfig(moduleId,fieldId)

• Example:

NamaRep.getValueFromModuleConfig("basic","value.info.useCurrentUserAsSalesMan")

This will get the value of the field: value.info.useCurrentUserAsSalesMan from global config

• Here are the available module names:

accounting
basic
supplychain
fixedassets
humanresource
dms
project
ecpa
manufacturing
srvcenter
crm
contracting
travel
realestate
housing
auditing
education
namapos
mc

NamaRep.security()
    .fieldEntityType("Account")
    .tableAlias("acc")
    .capabilities("firstAuthor", "viewCapability", "usageCapability", "updateCapability", "legalEntity", "branch", "sector", "department", "analysisSet")

NamaRep.security().fieldEntityType("Account")

.tableAlias("acc")

.capabilities(...)

.capabilities("legalEntity", "branch")

SELECT a, b, c
FROM Table1 t1
LEFT JOIN Table2 t2 ON t2.id = t1.someId
WHERE t1.code <> 'abc' AND $P!{SECURITY_CONSTRAINTS}

NamaRep.security()
    .fieldEntityType("Account")
    .tableAlias("Account")
    .capabilities("firstAuthor", "viewCapability")
+ " AND " +
NamaRep.security()
    .fieldEntityType("FiscalYear")
    .tableAlias("FiscalYear")
    .capabilities("legalEntity", "branch", "sector")

To translate a header and sub titles:

• Suppose that id = "xxx | yyy"
  • NamaRep.head(id) ⇒ xxx
  • NamaRep.sub(id) ⇒ yyy

Numeric Fields Helpers

NamaRep.zeroIfNull(fieldOrVariable)
NamaRep.oneIfZero(fieldOrVariable)
NamaRep.nullIfZero(fieldOrVariable)

How to create report with different pages sizes

Refer to development request SRDRQ05261

Kill Reports Running for more than n seconds

Refer to development request ECPADR00932

Tafqeet

• You can use any of the following expressions inside your jasper report:

NamaRep.tafqeet(currencyCode,number)
NamaRep.tafqeetArabic(currencyCode,number)
NamaRep.tafqeetEnglish(currencyCode,number)
NamaRep.tafqeetFrench(currencyCode,number)

The configuration for currencies tafqeet can be found in Tafqeet Info

Miscellaneous

• To use Arabic (hindu) numerals use '٠', '١', '٢', '٣', '٤', '٥', '٦', '٧', '٨', '٩'

NamaRep.arNumbers(value)

• To get saudi riyal symbol for reports, add an image, make the expression

NamaRep.sar()

• To get period between a start date and today, (years, months, days):
  • Create variable period with reset type none, increment type none
  • Variable expression should be:

java.time.Period.between(new java.util.Date($F{FromDate}.getTime()).toInstant().atZone(java.time.ZoneId.systemDefault()).toLocalDate(), java.time.LocalDate.now())

• Use the following in the text field expression you:

$V{period}.getYears()+"  "+"سنة"+"  "+$V{period}.getMonths()+"  "+"شهر"+"  "+$V{period}.getDays()+"  "+"يوم"

Here’s a clearer and more polished version of your text:

List Parameters (Multi-Selection)

To define a parameter that supports multiple selections, follow these guidelines:

• Set the property list = true.

• If the list is not of type Reference, you must also specify the listType property.

• To capture the selected values for display purposes, you can define additional parameters:

  • <parameterName>_csv: Receives the translated values as a CSV string.
  • <parameterName>_codecsv: Receives the codes of the selected values as a CSV string.
  • <parameterName>_name1csv: Receives the name1 fields of the selected values as a CSV string.
  • <parameterName>_name2csv: Receives the name2 fields of the selected values as a CSV string.

• To prevent the automatic display of the selection grid, set the property doNotAutoShowList = true.

<parameter name="MultiEmployee" class="java.util.List">
    <property name="entityType" value="Employee"/>
    <property name="arabic" value="الموظفين"/>
    <property name="english" value="Employees"/>
    <property name="property" value="code"/>
    <property name="list" value="true"/>
    <property name="doNotAutoShowList" value="false"/>
</parameter>

<parameter name="MultiEmployee_csv" class="java.lang.String" isForPrompting="false"/>

<parameter name="MultiDate" class="java.util.Date">
    <property name="english" value="Dates"/>
    <property name="arabic" value="التورايخ"/>
    <property name="defaultValue" value="$monthStart()"/>
    <property name="list" value="true"/>
    <property name="listType" value="java.util.Date"/>
</parameter>

<parameter name="MultiDate_csv" class="java.lang.String" isForPrompting="false"/>

Report Properties

• preRunUtil
• questionsChangeUtil
• comparisonType To use or change any of the previous properties, please consult the development team

Parameter Properties

Basic Properties

• list:

  • true or false
  • Indicates whether the parameter allows multiple selections (displayed as a selection grid).

• listType:

  • Required when using non-reference types (e.g., dates, numbers).
  • Example: java.util.Date, java.lang.Integer.

• layout:

  • Defines how the parameter is displayed.
  • Options: alone, spanned, normal, spanned2.

• required:

  • true or false
  • Marks the parameter as mandatory.

• requiredGroup:

  • Use the same value for multiple parameters to enforce that at least one of them must be filled.

• hijri:

  • true or false
  • Indicates whether the date should be displayed using the Hijri calendar.

Suggestions for Text Fields

• suggestionquery:

  • SQL query that returns values for suggestion/autocomplete in text input fields.

  • Two columns: First for code, second for Arabic display text.

  • Three columns: First for code, second for Arabic, third for English.

  Examples:

  SELECT DISTINCT TOP 25 revisionId, revisionName
  FROM ItemRevision
  WHERE invItem_id = {fItem}
    AND (revisionId LIKE '%' + {revision} + '%' OR revisionName LIKE '%' + {revision} + '%')


  SELECT DISTINCT revisionId
  FROM ItemDimensionsQty
  WHERE item_id = {fromItem}
    AND revisionId LIKE '%' + {revisionId} + '%'
    AND net <> 0


Reference Selection

• entityType:

  • The entity (table) from which records will be selected.

• allowedValues:

  • A comma-separated list of allowed values.
  • Will render any parameter as a combo box

• property:

  • The field to extract from the selected record (e.g., code, name1, name2, startDate).

• enumType:

  • Defines the enum type to use for allowed values.
  • Example enums: EntityTypeDF, SubsidiaryType, DocumentEntityTypeDF.

  Example:

  <parameter name="entityType" class="java.lang.String">
      <property name="enumType" value="EntityTypeDF"/>
      <property name="allowedValues" value="Employee,Vendor"/>
  </parameter>


Comparative and Display Properties

• type:

  • Comparison operators: > or <
  • For example, > will substitute negative infinity if no value is provided.

• arabic / english:

  • Arabic and English display labels.

• resource:

  • Resource key to use instead of specifying Arabic and English manually.

• src:

  • Used when you want to reuse a property from another parameter.

• ignore:

  • If set, the parameter is excluded from prompting (similar to isForPrompting = false).

Filtering Values

• filter:

  • Syntax: field,operator,value[,relation]
  • Multiple filters are separated by semicolons.
  • Default relation is AND.

  Operators:

  Equal, EqualOrEmpty, NotEqual, NotEqualOrEmpty,
  GreaterThan, GreaterThanOrEmpty, GreaterThanOrEqual, GreaterThanOrEqualOrEmpty,
  LessThan, LessThanOrEmpty, LessThanOrEqual, LessThanOrEqualOrEmpty,
  StartsWith, StartsWithOrEmpty, NotStartsWith, NotStartsWithOrEmpty,
  EndsWith, EndsWithOrEmpty, NotEndWith, NotEndWithOrEmpty,
  Contains, ContainsOrEmpty, NotContain, NotContainOrEmpty,
  OpenBracket, CloseBracket, In

  • Use ${parameterId} to reference the value of another parameter in filters.

  Examples:

  forType,Equal,Department,AND;isLeaf,Equal,true
  documentType,Equal,ReceiptVoucher
  forType,Equal,${subsidiaryType}


Default Values

• defaultValue:

  • String default value based on the parameter type:

    • Date: dd-MM-yyyy
    • Time: yyyy-MM-dd'T'HH:mm:ss.SSS
    • Reference: id:entityType:code

$now()
$today()
$monthStart()
$monthEnd()
$yearStart()
$yearEnd()
$currentFiscalPeriod()
$currentUser()
$currentEmployee()
$todayPlusDays(n)
$todayPlusWeeks(n)
$todayPlusMonths(n)
$todayPlusYears(n)
$quarterStart()
$quarterEnd()
$thirdStart()
$thirdEnd()
$halveStart()
$halveEnd()
$previousMonthStart()
$previousMonthEnd()
$nextMonthStart()
$nextMonthEnd()
$previousYearStart()
$previousYearEnd()
$nextYearStart()
$nextYearEnd()

• For multi-value parameters (List):

  • Use @A=@X to separate values.
  • Format: id:entityType:code@A=@Xid:entityType:code@A=@X...

Display Control & Validation

• NamaRep.canDisplay($P{param}):

  • Use in printWhenExpression to conditionally show elements based on parameter value.

• no-mirror = true:

  • Prevents mirroring of elements or bands.

Range Validation Between Parameters

• fromParam:

  • Links a "to" parameter to a "from" parameter to enforce range consistency.

• fromParamMaxGapInDays:

  • Defines the maximum allowed gap in days between two date parameters. Must be used with fromParam.

  Example:

  <parameter name="toDate" class="java.util.Date">
      <property name="arabic" value="إلى تاريخ"/>
      <property name="english" value="To Date"/>
      <property name="fromParam" value="fromDate"/>
      <property name="fromParamMaxGapInDays" value="30"/>
  </parameter>
